NZXT skříň H1 / mini ITX / 140 mm AIO chladič / 650W SFX-L 80Plus Gold modulární zdroj/riser card/USB-C/černá
Popis
Parametry
Hlídací pes
H1 - 13-liter Mini-ITX
The H1 is a small form factor case without the hassle, with pre-routed cables and an integrated PSU, AIO, and PCIe Gen3 Riser cable.
- Compact vertical design with support for most full-sized GPU’s on the market
- Toolless SSD tray and riser card for simple installation
- Pre-routed cables and downward-facing motherboard I/O faces down route all cables through the bottom of the case
- Integrated power supply, AIO liquid with pre-routed cables
- Integrated PCIe Riser card included for vertical GPU mounting
- Dual-chamber airflow
TECHNICAL SPECIFICATIONS
| Inside the Box | 1x H1 Case 1x 140mm AIO Liquid Cooler 1x SFX-L 650W 80 Plus Gold Power Supply 1x Aer P140mm Fan 1x PCIe 16x Gen3 High-Speed Riser Card 1x Breakout Cable 1x Installation Accessories 1x Manual |
| Dimensions (H x W x D) | 388 x 187 x 188 mm / 15.28 x 7.36 x 7.4 in |
| Weight | 6.53 kg / 14.4 lb |
| Compatibility & Clearance | |
| Max GPU Clearance | 305 x 128mm - 265 x 145mm |
| Max GPU Thickness | Up to 2.5 Slots |
| Memory Height | 45 mm |
| Front I/O Ports | |
| USB 3.2 Gen 1 Type-A | 1 |
| USB 3.2 Gen 2 Type-C | 1 |
| Headset Audio Jack | 1 |
| Expansion Slots | |
| Standard | 2 |
| Drive Bays | |
| 2.5" | 2 |
| 3.5" | - |
| Pump | |
| Dimensions | 65 x 65 x 27mm |
| Motor Speed | 4,200 ± 420RPM |
| Power | 12V DC, 0.3A |
| Connector | 3-pin |
| Radiator | |
| Dimensions | 139 x 174 x 22mm |
| Material | Aluminum |
| Compatible Socket & CPU | |
| Intel | Socket LGA 1200, 115X |
| AMD | AMD Socket AM4, FM2+, FM2, AM1, AM3+, AM3, AM2 |
| Fan Specs | |
| Model | Aer P 140mm |
| Speed | 500 - 1,800 ± 300RPM |
| Airflow | 27.27 - 98.17 CFM |
| Static Pressure | 0.21 - 2.71 mm-H2O |
| Noise | 21 - 38 dBA |
| Fan Connector | 4-pin PWM |
| Power Supply Specs | |
| Model | NP-S650M |
| Form Factor | SFX-L |
| Modular | Full |
| Wattage | 650W |
| Compliance Standard | SFX 12V V.3.3 / ATX 12V V.2.4 compatible with Intel V.1.31 |
| Energy Efficiency | 80 Plus Gold 20% loading: 87%, 50% loading: 90%, 100% loading: 87% @115Vac |
| Fan | 120mm FDB Fan |
| MTBF | 100,000 hours at 25°C. excluding the DC Fan. |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP |
| PCIe Expander Cable | |
| Form Factor | X16 |
| Compatibility | PCI-E 3.0 Passed |
| Cable Length | 315mm |
.
Provedení skříně:
Mini ITX
Barva skříně:
Černá
Počet pozic 2.5" (SSD):
2
Vybavení PC skříně:
S integrovaným zdrojem
Vybavení PC skříně:
Přední Audio panel
Vybavení PC skříně:
Přední USB panel
Výkon zdroje (W):
650
Aktuální cena produktu je7119Kč
s dph
